AVIPure® AAV Affinity Resins
AVIPure® AAV Affinity Resins provide capture step purification of adeno-associated virus (AAV) 2, 8, and 9 vectors with potential alkaline clean-in-place regeneration for improved process economics. A 50 µm cross-linked agarose matrix bead ensures compatibility with standard bioprocess columns and flow rates.
High performance at a lower price point
AAV process cost reduction
- ~20% lower resin cost/L
- > 20 cycle re-use, NaOH stable
- High binding capacity, yield, purity
Pre-packed or loose resin
- Available now: AAV2, AAV8, AAV9
- Available pre-packed in OPUS® Columns
- Redundant manufacturing at 3+ sites
- Worlds largest ligand manufacturer at 4+ sites
- 10+ year supply agreements
High performance at a lower price point
AVIPure® AAV 2, 8, and 9 Affinity Resins meet or exceed the performance metrics of resins developed on alternative platforms with the additional benefit of robust alkaline stability. Affinity resins offer the ability to simplify downstream processing. NaOH stable affinity resins simplify processes and dramatically improve overall process economics.
- Maintain high host cell protein (HCP) clearance and residual DNA clearance levels after 20 cycles
- Across life of the resin using 0.1 to 0.5 M NaOH for routine cleaning and sanitization
- High dynamic binding capacity even at short residence time enables use with pre-concentrated feed or direct capture:
- >2 x 1014 vp/mLresin at 1 minute residence time
- >7 x 1014 vp/mLresin at 4 minute residence time
Retain performance with NaOH CIP regeneration
Overlay of every fifth cycle from a single AVIPure® AAV2 column used in a 31-cycle study demonstrating robust chromatographic performance after cleaning in place with NaOH. Total NaOH exposure time at final cycle was 15 hours.
Consistently high yield and clearance of host cell protein (HCP) and host cell DNA (hcDNA) were achieved across 31 cycles on a single AVIPure® AAV2 column. Yield was measured using commercially available AAV2 Progen ELISA kits, HCP was measured by HCP ELISA, and hcDNA was measured by Picogreen assay. Average yield was 105%, average 4.0 log reduction of HCP to 977 ppm, and average 2.8 log reduction of hcDNA to 400 ppm.
Bind with 2-minute residence time, Clear more HCP and DNA
Bind, wash and elute direct capture of AAV cell culture feed (not concentrated) stream using AVIPure® AAV2 Resin.
A 2 -minute residence time enabled elimination of an existing pre-concentration step. Product was eluted in 50 mM glycine, 150 mM NaCl, 0.01% P188, pH 3 with 85% recovery.
AVIPure® AAV2 Resin and a competing AAV affinity resin were run under identical conditions. The eluted product was analyzed for purity by SDS-PAGE, HCP and residual DNA.
AVIPure AAV2 Resin and a competing AAV affinity resin were run under identical conditions (2 minute residence time) with the eluted product analyzed for purity by SDS-PAGE, HCP and residual DNA. AVIPure AAV2 Resin delivered purified product with 7-fold lower residual HCP, 1.5X lower residual DNA and fewer impurity proteins by SDS-PAGE.
AVIPure® AAV2 Resin delivered purified product with 7-fold lower residual HCP.
|填料||残留 HCP||残留 DNA|
|AVIPure® AAV2 Resin||4400 ppm||2400 ppm|
|供应商 A||33000 ppm||4000 ppm|
AVIPure® AAV2 Resin delivered purified product with 1.5X lower residual DNA and fewer impurity proteins by SDS-PAGE.
|2||AVIPure® NaOH CIP|
|4||竞品 NaOH CIP|
SPEED TO MARKET
Available pre-packed in OPUS® Columns for quick deployment
AVIPure® AAV affinity resins are available in pre-packed and pre-qualified OPUS® Columns for rapid GMP implementation as well as in loose resin formats.
AVIPure® AAV2, 8, 9 Resin characteristics
|粒径 (d 50 V )||~ 50 µm|
AAV2 和 AAV8: 耐碱重组蛋白（无动物源性）
AAV8 和 AAV9: 氨基甲酸酯
High dynamic binding capacity even at short residence time enables use with pre-concentrated feed or direct capture:
|缓冲液兼容性||对所有常用的水性缓冲液稳定，包括 8 M 尿素、6 M 盐酸胍、乙二醇和去污剂|
|溶剂兼容性||水、乙醇 (0–20% v/v)、乙腈、1–2 M 乙酸、其它常见有机溶剂|
|在线清洗稳定性||0.1-0.5 M NaOH|
|压力/流速 a||3 bar @ >300 cm/hc|
|最高压力 (ΔP)a||40 psi|
|发货状态||2 % 苯甲醇|
|储存||2–8 °C, 2% benzyl alcohol or 18-20% ethanol; do not freeze|
|a 2.6 x 20 cm层析柱，以4 bar压力装柱|
